Add and Remove View dynamically

We can use addView() and removeView() to add/remove views programmically. Also we can call removeAllViews() to remove all child views.

main.xml, the main layout. The FrameLayout, master, is the parent ViewGroup used to add/remove view.

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:layout_width="fill_parent"
android:layout_height="fill_parent"
android:orientation="vertical" >

<TextView
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:text="@string/hello" />
<LinearLayout
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:orientation="vertical" >
<CheckBox
android:id="@+id/enlayer1"
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:text="Enable Layer 1"/>
<CheckBox
android:id="@+id/enlayer2"
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:text="Enable Layer 2"/>
<CheckBox
android:id="@+id/enlayer3"
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:text="Enable Layer 3"/>

</LinearLayout>
<FrameLayout
android:id="@+id/master"
android:layout_width="fill_parent"
android:layout_height="fill_parent"
android:orientation="vertical" />

</LinearLayout>

Create three layout files. They are the child view to be added/removed using Java code.

layer_1.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:layout_width="fill_parent"
android:layout_height="fill_parent"
android:orientation="vertical">

<TextView
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:text="Layer 1" />
<EditText
android:hint="EditText"
android:layout_width="fill_parent"
android:layout_height="wrap_content"/>

</LinearLayout>

layer_2.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:layout_width="fill_parent"
android:layout_height="fill_parent"
android:orientation="vertical">

<TextView
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:gravity="center"
android:text="Layer 2" />

<CheckBox
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:text="CheckBox A"/>
<CheckBox
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:text="CheckBox B"/>
<CheckBox
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:text="CheckBox C"/>

</LinearLayout>

layer_3.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:layout_width="fill_parent"
android:layout_height="fill_parent"
android:orientation="vertical">

<TextView
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:gravity="right"
android:text="Layer 3" />

<ImageView
android:layout_width="fill_parent"
android:layout_height="fill_parent"
android:src="@drawable/ic_launcher"
android:layout_gravity="center"
/>

</LinearLayout>

Main code, AndroidDynViewActivity.java.

package com.exercise.AndroidDynView;

import android.app.Activity;
import android.os.Bundle;
import android.view.LayoutInflater;
import android.view.View;
import android.widget.CheckBox;
import android.widget.CompoundButton;
import android.widget.FrameLayout;

public class AndroidDynViewActivity extends Activity {

FrameLayout mainLayer;
View layer1, layer2, layer3;
CheckBox enableLayer1, enableLayer2, enableLayer3;

/** Called when the activity is first created. */
@Override
public void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.main);

enableLayer1 = (CheckBox)findViewById(R.id.enlayer1);
enableLayer2 = (CheckBox)findViewById(R.id.enlayer2);
enableLayer3 = (CheckBox)findViewById(R.id.enlayer3);

mainLayer = (FrameLayout)findViewById(R.id.master);

LayoutInflater inflater = getLayoutInflater();
layer1 = inflater.inflate(R.layout.layer_1, null);
layer2 = inflater.inflate(R.layout.layer_2, null);
layer3 = inflater.inflate(R.layout.layer_3, null);

enableLayer1.setOnCheckedChangeListener(enableLayer1ChangeListener);
enableLayer2.setOnCheckedChangeListener(enableLayer2ChangeListener);
enableLayer3.setOnCheckedChangeListener(enableLayer3ChangeListener);

}

CheckBox.OnCheckedChangeListener enableLayer1ChangeListener
= new CheckBox.OnCheckedChangeListener(){

@Override
public void onCheckedChanged(CompoundButton buttonView,
boolean isChecked) {
if(isChecked){
mainLayer.addView(layer1);
}else{
mainLayer.removeView(layer1);
}
}
};

CheckBox.OnCheckedChangeListener enableLayer2ChangeListener
= new CheckBox.OnCheckedChangeListener(){

@Override
public void onCheckedChanged(CompoundButton buttonView,
boolean isChecked) {
if(isChecked){
mainLayer.addView(layer2);
}else{
mainLayer.removeView(layer2);
}
}
};

CheckBox.OnCheckedChangeListener enableLayer3ChangeListener
= new CheckBox.OnCheckedChangeListener(){

@Override
public void onCheckedChanged(CompoundButton buttonView,
boolean isChecked) {
if(isChecked){
mainLayer.addView(layer3);
}else{
mainLayer.removeView(layer3);
}
}
};

}

Download the files.
